LGA36400CU33X – Square D – Molded Case Circuit Breakers

Overview

Product Specifications – LGA36400CU33X – Square D Molded Case Circuit Breakers

• Part Number:

  LGA36400CU33X

• Manufacturer:

  Schneider Square D Breakers

• Family:

  Powerpact

• Pole:

  3

• Amp:

  400

• Volt:

  600

• Phase:

  3

Product Description – LGA36400CU33X – Square D Molded Case Circuit Breakers

PowerPacT L-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT L-Frame circuit breakers are available with electronic trip units. All PowerPacT L-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT L circuit breakers are available in 3 and 4-pole unit mount, I-Line, and drawout constructions. This PowerPacT L, 400A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker provides MicroLogic Standard with a 3.3S trip unit and an LSI function. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This circuit breaker has a continuous current rating of 100% with an ABC phase connection. PowerPacT L circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked
